9.5.3. Time/Date Format
This option determines the format in which the time and date are displayed.
The following options are available:

DD/MM/YY, 24Hr

DD/MM/YY, 12Hr
To program the Time/Date format:
1. From the Programming menu, select System Options, Display, and Time Format [94053].
2. Select the required format from the options available.
9.5.4. Supervision Loss Indication
This option enables you to select whether the system trouble display will indicate transmitter
supervision loss to the user.
To program the Supervision Loss Indication setting:
1. From the Programming menu, select System Options, Display, and SV Loss Ind. [94054].
2. Select Enabled or Disabled.
9.6.

PGM Output Options

The PGM is a programmable output that is triggered according to specific system status conditions, or
by remote command sent via PSTN, GSM, keyfob, RP, or via Internet (ELAS versions 321 and above).
9.6.1. Output Trigger
The Output Trigger option determines the conditions that activate and deactivate the PGM output.
To program the Output Trigger:
1. From the Programming menu, select System Options, PGM Options, and Output Trigger
[94061].
2. Select an Output Trigger option from the following table.
Table 9-1: PGM Output Trigger Options
Trigger
Option
PGM Not
Used
Full Arm
Perimeter
Arm
Part Arm
Arm Status
Power
Trouble
Tel. Line
Trouble
System
Trouble
Medical
56
görünmesini istediğiniz metne Heading 1 uygulamak için Giriş sekmesini kullanın.
Activated by...
The PGM output is disabled
System "Full" armed
System "Perimeter" armed
System "Part" armed
Any arming method
AC Loss or Low Battery conditions
Telephone line supervision trouble
System trouble condition
Medical alarm

MM/DD/YY, 24Hr

MM/DD/YY, 12Hr
Deactivated by...
System disarmed or PGM Cut-off
AC restore or Battery restore
Telephone line restore
System trouble restore
Any arming method, system disarmed
