11. Internet Options

The following options concern the configuration of the GPRS. In most cases, the Internet options
will be pre‐programmed as defaults and you will not be required to change any of the settings apart
from the CPID and password for each customer.
11.1.

ELAS Connection Parameters

The following parameters, required to connect Control System to ELAS, are set by ELAS
administrator.
11.1.1. XML Proxy IP
To edit the XML Proxy IP:
1. From the Programming menu, select Communications, Internet, XML Proxy IP [9571].
2. Enter the XML Proxy IP provided by your ELAS administrator. Use the ʺ1ʺ key to enter
ʺ.ʺ, key to insert and the
finished.
11.1.2. XML Proxy Port
To edit the XML Proxy Port:
1. From the Programming menu, select Communications, Internet, XML Proxy Port [9572].
2. Enter the XML Proxy Port provided by your ELAS administrator. Use the ʺ1ʺ key to enter
ʺ.ʺ, key to insert and the
finished.
11.2.

Control System Parameters

The following parameters, required to connect Control System to ELAS, should be provided by
your ELAS administrator.
11.2.1. CP ID
To edit the Control System ID:
1. From the Programming menu, select Communications, Internet, CP ID [9573].
2. Enter the unique Control System ID provided by your ELAS administrator to connect the
Control System to ELAS. Use the ʺ1ʺ key to enter ʺ.ʺ,
delete one character at a time. The ID length must be six up to sixteen characters. Press ʹ√ʹ
when finished.
11.2.2. CP Password
To edit the Control System Password:
1. From the Programming menu, select Communications, Internet, CP Password [9574].
2. Enter the Control System Password provided by your ELAS administrator to connect the
Control System to ELAS. Use the ʺ1ʺ key to enter ʺ.ʺ,
delete one character at a time. The password length must be six up to sixteen characters.
Press ʹ√ʹ when finished.
CommPact Installation Manual
key to delete one character at a time. Press ʹ√ʹ when
key to delete one character at a time. Press ʹ√ʹ when
key to insert and the
key to insert and the
key to
key to
