6.

PGM Control

The purpose of this chapter is to explain the various methods used to control PGM output. PGM is a
programmable output that is triggered according to specific system status conditions, or by remote
command sent via PSTN, GSM, keyfobas explained below.
6.1.

Keyfob Control

You can control PGM using any of the four button keyfobs registered to the system. For further
information on how to assign keyfob B2 button to PGM, see p. 45, 7.4.2 PGM Assignment.
6.2.

Telephone Control

You can send On and Off commands to PGM output by SMS messages sent from a cellular phone
to the Control System. Alternatively, PGM can be controlled by DTMF commands during
Telecontrol call (either cellular or landline). For this feature to function correctly, Telephone control
must be enabled for PGM – see p.56, 9.6.1 Output Trigger.
6.2.1. DTMF Command
Using the Telecontrol feature, you can turn on and off PGM output via the telephone with DTMF
commands. For further information on the Telecontrol features, see p. 35 5 Telecontrol and Two‐
Way Audio and PGM DTMF commands.
6.2.2. SMS Command Format
Each SMS command for PGM control must contain the following elements:

SMS Command Descriptor (Optional, up to
43 characters of free text)

Delimiter # (Mandatory, separates the
descriptor from the actual command)
The following example shows the format of an SMS command to switch PGM On.
While the SMS Command Descriptor is optional, you must start the SMS command with
the # symbol for the system to accept the command.
6.2.3. SMS Confirmation Message Format
After an SMS command is executed, the system can return a confirmation SMS message to the
sender. This message includes the PGM descriptor and the command that was sent. For further
information on how to enable this feature, see p. 72, 10.7.5 SMS Confirmation.
This message is sent when the parameter 'SMS Confirm' (Programming, Communications, Comm.
Options, GSM Options, SMS Confirm [954135]) is Enabled.
The following example shows the confirmation message the sender receives for the sample
command from the previous section:
38
görünmesini istediğiniz metne Heading 1 uygulamak için Giriş sekmesini kullanın.
 
P G M O N # 1
P G M

User Code (4 digits)
 Command (0=Off, 1=On)

Device Number (30 for PGM output)
  
2 3 4 1 3 0
O N
