To delete a device:
1. From the Programming menu, select Devices, [91].
2. Select the specific device you want to delete.
3. From the device's sub‐menu, select Delete.
4. Press ʹ√ʹ to confirm; the device is deleted.
7.2.3.

Supervision Time

The detectors in Electronics Line 3000's supervised wireless range send a supervision signal
approximately 20 minutes after its last transmission. If the system does not receive supervision
signals from a specific transmitter, the transmitter is regarded as inactive.
The amount of time after which a transmitter is considered inactive is called the Supervision Time.
There is a separate supervision time for general transmitters and devices that are registered to
Fire zones.
To program the Supervision Time for general transmitters:
1. From the Programming menu, select Devices, Superv. Time, General [9161].
2. Enter a supervision time between 02:00 and 23:59 hours.
To program the Supervision Time for transmitters registered to Fire zones:
1. From the Programming menu, select Devices, Superv. Time, Fire [9162].
2. Enter a supervision time between 02:00 and 23:59 hours.
7.2.4. Re-Synchronization
Transmissions that are out of synchronization are rejected by the system. For example, it is not
possible to arm or disarm the system using a keyfob that is out of synchronization. In the event that
a transmitter is out of synchronization, it is possible to re‐synchronize the transmitter and restore
normal operation.
To re‐synchronize transmitters:

From the Programming menu, select Devices, TX Re‐synch [917]; a 10‐minute time
window is opened.
During the 10‐minute time window, if a transmission is received that is out of
synchronization, the transmitter is re‐synchronized.
