Installer Utilities
The EL‐2635 repeater offers two installer utilities that serve as a valuable aid during installation and
maintenance.
TX List
The TX List is a scrollable inventory of all transmitters that are registered to the repeater and their
last reported signal strength.
To view the TX list:
1. Press  until 1. TX List appears on the display.
2. Press ʹ√ʹ; the first transmitter in the list is displayed.
3. Use the arrow navigation keys (/) to scroll through the list.
4. Press Χ to exit the list.
TX Test:
TX Test is a utility that enables you to identify transmitters that are registered to the repeater and to
test their signal strength.
To perform the TX test:
1. Press  until 2. TX Test appears on the display.
2. Press ʹ√ʹ.
3. Activate a transmitter; the transmitter number, type and signal strength are displayed.
4. Press Χ to exit TX Test mode.
