Summary of Contents for Electronics Line Infinite Prime

  • Page 2 Catalog Number: ZI0644A (11/2008) All data is subject to change without prior notice. Hereby, Electronics Line 3000 Ltd. declares that this control system is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Copyright © 2008 Electronics Line 3000 Ltd. All rights reserved.

  • Page 3: Table Of Contents

    Table of Contents Chapter One: Introduction..........................5 1.1: Documentation Conventions ......................5 1.2: Specifications ..........................6 1.3: System Overview ..........................6 1.4: Hardware Layout ..........................8 Chapter Two: System Installation .......................13 2.1: Pre-Installation Planning .......................13 2.2: Installation Procedure ........................14 2.3: Back Tamper..........................17 2.4: Installing Hardwire LCD Keypads....................18 Chapter Three: Basic System Operation ....................20 3.1: Front Panel Layout........................20 3.2: System Status LEDs ........................20...
  • Page 4 9.1: Swinger Setting ..........................57 9.2: Code Lockout ..........................57 9.3: Arm/Disarm Options ........................57 9.4: Panic Alarm...........................59 9.5: AC Loss Delay ..........................59 9.6: Display Options ..........................59 9.7: PGM Output Options ........................60 9.8: Guard Code (future option) ......................62 9.9: “No Arm” Indication ........................62 9.10: Jamming Detection ........................62 9.11: “No Motion”...

  • Page 5: Chapter One: Introduction

    Chapter One: Introduction This manual is designed to help you install the infinite prime control system. We strongly urge you to read through this manual, in its entirety, before beginning the installation process so that you can best understand all that this security system has to offer. This manual is not intended for end user use.

  • Page 6: Specifications

    Operating Temperature: 0-60°C 1.3: System Overview The infinite prime is a full-featured wireless control system that is expected to provide a solution to the needs of most residential installations. This system has been developed based upon a design concept geared towards easy installation and use. With this in mind, the user interface is based on a simple, menu-driven model that suits the essential requirements of both the user and installer alike.
  • Page 7 Central station communication and up/downloading employ either regular PSTN or high-speed cellular communication. SMS messaging provides an innovative method used for both central station and Follow-me user monitoring. Additionally, SMS messages can be sent to the control system enabling the user to send commands to the system from anywhere on the planet. The control system’s home automation capabilities provide a wealth of features.

  • Page 8: Hardware Layout

    1.4: Hardware Layout The aim of this section is to acquaint you with the various circuit boards that make up the system. Apart from the Main Board, each peripheral module is available as an optional extra designed for installation inside the plastic housing. Figure 1.2: System Layout Main Board PSTN dialer module (optional)
  • Page 9 1.4.1: The Main Board The Main Board is the brain of the system and connects to various peripheral modules using a number of interface connectors. Additionally, the Main Board includes a programmable output, a hardwire zone input and a USB port for PC programming. Figure 1.3: Main Board USB port for connection to PC DIP-switch for flash programming...
  • Page 10 1.4.2: PSTN Module The PSTN module provides the system with a standard dialer for communication via the Public Switched Telephone Network (PSTN). Do not use VoIP phone lines for communication to the central monitoring station. In certain cases the system may not transmit alarm signals successfully over the VoIP network. Alternative Telephone Line Socket...
  • Page 11 Figure 1.5: Home Automation Module (with internal PLI) Interface connector to Main Board Flash programming connector Power-line terminal connections to Main Board (1 - Neutral; 2 - Live) Figure 1.6 shows the HA module used in the systems with external PLI. Figure 1.6: Home Automation Module (with external PLI) Interface connector to Main board Status LED...
  • Page 12 1.4.4: Cellular Communications Module The Cellular Communications module enables the control system to communicate via cellular networks. This offers the ability to send or receive SMS messages, perform up/downloading, implement cellular 2-way voice applications. Figure 1.8: Cellular Communications Module SIM card holder SIM card release Status LED Flash programming connector...

  • Page 13: Chapter Two: System Installation

    Chapter Two: System Installation The following chapter explains how to install the system and provides guidelines and tips on how to optimize the installation. It is recommended that you familiarize yourself with the various circuit boards that make up the system – see 1.4: Hardware Layout. 2.1: Pre-Installation Planning Before starting the installation procedure, it is worthwhile to draw a rough sketch of the building and determine the required position for the control system and each...

  • Page 14: Installation Procedure

    Figure 2.2: Considering Construction Materials • The reduction of the RF signals’ strength is directly proportional to the thickness of the obstacle, assuming that the obstacles are of identical material. Figure 2.3: Considering Thickness of Obstacles 2.2: Installation Procedure After unpacking the kit and making certain that you have all the necessary equipment, it is recommended that you install the system as follows: STEP 1: Open the housing.
  • Page 15 2.2.2: Step 2 – Powering Up the System In order to register and test transmitters, it is necessary to temporarily power up the system before installing the control system. At this stage, do not connect the backup battery. Thread the power cable through the wiring hole on the back cover and connect the cable to the AC power input on the Main board.
  • Page 16 Activate the transmitter you wish to test; the transmitter’s details appear on the control system’s LCD. Additionally, between one and four tones are sounded to indicate the transmitter’s signal strength. If four tones are sounded, the transmitter is in the best possible location – see 4.7.7: Transmitters for further information.

  • Page 17: Back Tamper

    Place the control system in position against the wall and mark the upper and lower mounting holes. If using the back tamper, also mark the hole for the back tamper screw. Install wall anchors in the appropriate positions. Thread any required cables through the wiring hole on the back cover (e.g.

  • Page 18: Installing Hardwire Lcd Keypads

    2.4: Installing Hardwire LCD Keypads The system supports hardwire LCD keypads that may be installed up to 300m from the control system. LCD Contrast Flash Potentiometer Programming Connector Terminal Block Tamper Switch Figure 2.7: Hardwire LCD Keypad (back cover off) To install hardwire LCD keypads.
  • Page 19 Make certain the keypad’s tamper switch is open. keypad, press keys simultaneously. Use the arrow keys ( / ) to select the keypad address. Press Position the front cover’s top holding hooks onto the back cover and snap the front cover closed. After installing hardwire keypads, perform the Find Modules function –...

  • Page 20: Chapter Three: Basic System Operation

    Chapter Three: Basic System Operation 3.1: Front Panel Layout The front panel provides a detailed interface for operating and programming the system. The following diagram will familiarize you with the various elements on the front panel. Display System Status LEDs Arming Menu Keys...

  • Page 21: Front Panel Keypad

    3.3: Front Panel Keypad The alphanumeric keypad on the front panel enables you to perform various operation and programming tasks. Apart from the regular functions of a standard alphanumeric keypad, the keypad offers a number of special functions. These functions are listed in the following table.

  • Page 22: Vocal Message Annunciation

    Table 3.5: System Status 3.4.2: System Trouble Tones In the event of system trouble, the infinite prime sounds a series of tones to alert the user. To silence these tones, press and scroll through the system trouble list displayed on the LCD.

  • Page 23: Hardwire Lcd Keypad

    3.6: Hardwire LCD Keypad In addition to the front panel keypad, you can install up to three, individually addressed, hardwire LCD keypads (or two keypads with large LCD). The layout of the hardwire LCD keypad is similar to the front panel keypad and most of the functionality is identical. The following diagram shows the layout of the hardwire LCD keypad.

  • Page 24: Arming/Disarming

    The following section explains how to arm and disarm the control system using the LCD keypad. The infinite prime offers three arming modes that you can define to suit the application. Figure 3.4 illustrates the three arming modes. In each diagram, the protected area is shaded.
  • Page 25 To partially arm the system using the hardwire LCD keypad: Check if the system is ready to arm. Press PART on the keypad. Select Part arming. If One-Key Arming is disabled, enter your user code. 3.7.4: Perimeter Arming Perimeter arming is designed for when the occupant intends to remain inside the premises and secure the perimeter.

  • Page 26: Remote Arming/Disarming Via Sms

    3.7.6: Forced Arming Forced arming enables you to arm the system when the system is not ready. For example, if a door protected by a magnetic contact is open, you may arm the system on condition that the door will be closed by the end of the Exit delay. If the door is still open after the exit delay expires, an alarm is generated.

  • Page 27: Remote Arming/Disarming Via Dtmf

    While the SMS Command Descriptor is optional, you must start the SMS command with the # symbol for the system to accept the command. After an SMS command is executed by the system, you can program the system to return a confirmation message to the sender – see 10.7.5: SMS Confirmation. 3.8.1: Arm Status Reply On receiving an Arm Status request message, the system returns a status message to the sender.
  • Page 28 Figure 3.8: Fire Alarm Activation To activate a Medical alarm from the front panel or hardwire LCD keypad: • Press keys 4 and 6 simultaneously. Figure 3.9: Medical Alarm Activation -28-...

  • Page 29: Chapter Four: Advanced System Operation

    Chapter Four: Advanced System Operation Besides the basic arming functions described in the previous chapter, you can access additional functions via the menu. This chapter describes these functions and the menu navigation procedure. 4.1: Menu Navigation Alphanumeric Keypad Menu Navigation Keys HA Off Key HA On Key...

  • Page 30: Sensor Bypassing/Unbypassing

    4.3: Sensor Bypassing/Unbypassing When a sensor is bypassed, it is ignored by the system and does not generate an alarm when triggered. To bypass or unbypass a sensor: From the Bypass Zones menu, select Bypass/Unbyp. [21]. Using the arrow keys, scroll to the sensor you want to bypass or unbypass. Press to change the bypass status.
  • Page 31 Code 28: Duress Code The Duress code is designed for situations where the user is being forced to operate the system. This user code grants access to the selected operation, while sending a Duress event message to the central station. Code 29: Telecontrol Code The Telecontrol code is designed to enable the user to perform a number of tasks via their telephone using DTMF commands.

  • Page 32: Follow Me

    4.4.3: User Code Descriptors Each user code can be assigned a 16-character descriptor. These descriptors help to identify users in the event log and in SMS Follow Me messages. To edit a code descriptor: From the main menu, select User Codes [4]. Select a code.

  • Page 33: Service Menu

    Press ; the log is cleared. For certain versions of the infinite prime software, the Clear Log function may be disabled. 4.7: Service Menu The Service menu is accessible using either the Installer or Master code. This menu includes various functions that enable you to test the system effectively.
  • Page 34 To record a message: From the Service menu, select Messages, Record Message [7022]. Press to start recording the message. Record your message. The message may be up to twenty seconds long. Press to stop recording; the message is automatically played back and OK? is displayed.
  • Page 35 To view the TX list: From the Service menu, select Transmitters, TX List [7071]; the first transmitter on the list is displayed. Using the arrow buttons, scroll through the transmitter list. When you have finished viewing, press to exit the list. The TX list displays the following information for ZONE #2 each transmitter:...
  • Page 36 Press… To… Increase microphone sensitivity Reduce microphone sensitivity Increase speaker volume Reduce speaker volume Table 4.3: Voice Level Adjustment Press ; the new settings are stored in the memory. 4.7.9: GSM Signal Strength You can measure the GSM signal strength using the system’s RSSI (Received Signal Strength Indication) meter.

  • Page 37: Chapter Five: Telecontrol And Two-Way Audio

    Chapter Five: Telecontrol and Two-Way Audio The infinite prime control system offers a range of Telecontrol features that provide remote access via the telephone. These features include Two-Way Audio, remote arming/disarming and cancel siren activation. This chapter explains these features and their operation procedures.
  • Page 38 To make a Telecontrol call: Call the control system either using the double call method (PSTN) or directly (Cellular); when the control system picks up, two DTMF tones are sounded. Enter the Telecontrol code (Code 29) on your telephone within 15 seconds. Do not enter your user code until you hear the two DTMF tones.

  • Page 39: Outgoing Calls

    5.2: Outgoing Calls The infinite prime control system can make Two-Way Audio calls to the user or central station in the event of an alarm. This feature is designed for applications such as alarm verification, panic and medical emergency.
  • Page 40 5.2.2: TWA Alarm Reporting In the event of Burglary, Fire and Medical alarms, the control system is able to report the events and then stay on the line after ACK 2 is received. This allows the operator to verify the alarm or provide assistance in the event of an emergency. For this feature to function, you must enable Two-Way Audio for both the account and the event group.
  • Page 41 5.2.4: TWA Follow-Me The TWA Follow-Me feature is designed to establish a Two-Way Audio connection with the user in the event of an alarm. For this feature to function, the account’s protocol must be defined as TWA Follow-Me. The sequence for a Two-Way Audio Follow-me call is as follows: An alarm occurs.

  • Page 42: Chapter Six: Home Automation And Pgm Control

    Chapter Six: Home Automation and PGM Control The purpose of this chapter is to explain the various methods used to control X10 Home Automation (HA) units installed around the home, and PGM output.The PGM is a programmable output that is triggered according to specific system status conditions, or by remote command sent via PSTN, GSM, keyfob, keypad, or RP as explained below.

  • Page 43: Scheduling (Not Relevant To

    6.3.2: SMS Command Format Each SMS command contains the following elements: SMS Command Descriptor (up to 43 characters of free text) # (delimiter – separates the descriptor from the actual command) User Code (4 digits) Command (0=Off, 1=On) Device Number (HA Units: 01-16, or 30 for PGM output) The following example shows the format of an SMS command to switch on a water boiler controlled by HA unit 8.
  • Page 44 6.4.3: Weekly Schedule To program the days of the week that the schedule is active: From the main menu, select HA Schedules [8]. Select an HA unit. From the HA unit’s sub-menu, select Schedule [#3]. Use keys 1 to 7 to toggle the days on and off. Press…...

  • Page 45: Chapter Seven: Devices

    Chapter Seven: Devices This chapter explains how to register devices to the system and the programming options for each device. For further information, please refer to the installation instructions included with each device. 7.1: Device Registration For the system to recognize individual devices, each device must be registered to the system.

  • Page 46: Supervision Time

    7.6: Zones The infinite prime includes 33 security zones. Zones 1-32 are intended for wireless sensors. One sensor can be registered to each wireless zone. The system supports Electronics Line 3000’s supervised wireless range of transmitters that includes various PIR sensors, magnetic contacts and smoke detectors.
  • Page 47 7.6.1: Zone Type The zone type defines the type of alarm the system generates when the sensor is tripped. To program a zone type: From the Programming menu, select Devices, Zones [911]. Select the sensor you want to program. From the sensor’s sub-menu, select Zone Type [#02]. Select one of the following zone types: •...
  • Page 48 If the Bell option is enabled for Environmental or Flood zones, the system sounds trouble tones from the keypad. 7.6.4: Chime When Chime is enabled, triggering the zone when the system is disarmed causes the internal siren to chime. To program the Chime option: From the Programming menu, select Devices, Zones [911].

  • Page 49: Keyfobs

    Select either No Repeater or Use Repeater. 7.7: Keyfobs The infinite prime supports two types of keyfob transmitter, EL-2611 and EL-2614/EL- 2614E. You can register up to 19 keyfobs to the system. Figure 7.1 illustrates these transmitters and the functions assigned to their buttons. For information on registration, descriptor editing and deletion, see 7.1: Device Registration, 7.2: Device Descriptors,...

  • Page 50: Keypads

    Select the HA unit you want the button to control (01-16, or 30 for PGM output) or enter 00 to program the button’s default function. The default functions are as follows: B1: Part arming B2: Perimeter arming 7.7.3: SOS Panic Alarm Activation (EL-2614/EL-2614E) Using the four-button keyfob, you can activate an SOS Panic alarm by pressing two buttons simultaneously.

  • Page 51: Repeaters

    7.9: Repeaters Repeaters are designed to extend the wireless range of the control system. Up to four repeaters may be registered to the system with a maximum of 32 transmitters associated with each receiver. For information on registration, descriptor editing and deletion, 7.1: Device Registration, 7.2: Device Descriptors, and 7.3: Device Deletion , respectively.

  • Page 52: Smartkeys

    7.10.2: Wireless Siren Delay The Wireless Siren Delay is the period of time during which the wireless siren is not sounded after an alarm is triggered by normal, follower or 24Hr zones. This feature is implemented only when the system is not fully armed. During the Wireless Siren Delay, the control system’s built-in siren is sounded but the alarm report is not sent until the delay has expired.

  • Page 53: Chapter Eight: Entry/Exit Timers And System Tones

    Chapter Eight: Entry/Exit Timers and System Tones This chapter explains how to program the time of the Entry/Exit delays and the tones sounded by the built-in siren and wireless siren during Exit/Entry delays, arming, disarming, home automation operation and when a trouble condition is present. 8.1: Entry/Exit Delay The Entry/Exit delay timers determine the amount of time the user has to arm or disarm the system before an alarm is activated.

  • Page 54: Entry Deviation

    8.4: Entry Deviation Entry Deviation is a pre-alarm feature employed in the event that a sensor defined with the “Normal” zone type is opened during the entry delay. In this case, the control system’s built-in siren is sounded until the end of the entry delay period. Failure to disarm by the end of the entry delay causes the system to generate an alarm.

  • Page 55: Home Automation Tones

    To program tones sounded by the built-in siren on arming: From the Programming menu, select Tones, Arm Tones, Siren [9332]. Select Enabled or Disabled. 8.6.4: Disarming Tones To program tones sounded by the wireless siren on disarming: From the Programming menu, select Tones, Disarm Tones, WL Siren [9341]. Select Enabled or Disabled.

  • Page 56: Tones Options

    To program the Fire Trouble Tones option: From the Programming menu, select Tones, Fire Trb. Tones [938]. Select Enabled or Disabled. It is not necessary to program the Telephone Trouble Tones and Fire Trouble Tones options if the Trouble Tones option is programmed as disabled. 8.9: Tones Options 8.9.1: Tones Output The Tones Output option enables you to determine whether the tones sounded when arming...

  • Page 57: Chapter Nine: System Options

    Chapter Nine: System Options As the name suggests, System Options are settings that affect the entire system. This chapter offers explanations and programming instructions for each of these options. 9.1: Swinger Setting A sensor defined as Swinger enabled can generate only a limited number of alarms during a specific time period or during an arming period.
  • Page 58 9.3.3: Supervised Arm The Supervised Arm option is a feature designed to supervise intrusion sensor activity before you arm the system. If the system has not received a transmission from a sensor during the interval defined for this option, all arming methods that include that sensor shall not be available. Medical, Panic, Fire, Gas, Flood, and Environmental zones are not included in this supervision and do not affect the system’s ability to arm.

  • Page 59: Panic Alarm

    To program the Keyfob Arm option: From the Programming menu, select System Options, Arm/Disarm, KF Arm [94036]. Select With Exit Delay or No Exit Delay. Press when the desired setting is displayed. 9.4: Panic Alarm SOS Panic alarms generated from the front panel, keypads or keyfobs can be defined as either audible or silent.

  • Page 60: Pgm Output Options

    To edit the Banner text: From the Programming menu, select System Options, Display, Banner [94062]. Edit the Banner text using the alphanumeric keypad. Press when you have finished editing. The system never displays the Banner text if the Arm Status Display option is programmed as Always.
  • Page 61 Trigger Option Activated by… Deactivated by… PGM Not Used The PGM output is disabled Full Arm System “Full” armed System disarmed Perimeter Arm System “Perimeter” armed Part Arm System “Part” armed PGM Cut-off Arm Status Any arming method Power Trouble AC Loss or Low Battery conditions AC restore or Battery restore Tel.

  • Page 62: Guard Code (Future Option)

    9.8: Guard Code (future option) The Guard Code is a future option that is not available in the current firmware. The default setting for this option is disabled. Electronics Line 3000 recommend that you do not change this setting. 9.9: “No Arm” Indication The “No Arm”...

  • Page 63: Microphone/Speaker Options

    9.12: Microphone/Speaker Options In addition to the built-in microphone and speaker, the infinite prime control system supports external microphone/speaker unit called “infinite-Interphone”. Microphone/Speaker option allows you to choose which microphone and speaker are in use. You can choose one mic./speaker (internal or external) to function exclusively or both may function simultaneously.

  • Page 64: Report Fail Trouble

    9.19: Cross Zoning (future option) Cross Zoning is a future option that is not available in the current firmware. The default setting for this option is disabled. Electronics Line 3000 recommend that you do not change this setting. 9.20: Verified Fire The Verified Fire feature is an option that is designed to delay Fire alarm reports to the central station until the alarm condition has been verified.

  • Page 65: Battery Type

    • An alarm occurs from a Fire zone, the alarm is restored and then a second alarm occurs from the same zone during the Verified Fire timeout – in this case, the alarm is reported immediately on receiving the second alarm. •...

  • Page 66: Chapter Ten: Communications

    Chapter Ten: Communications This section explains how to determine the way the control system communicates via the GSM and PSTN modules. 10.1: Central Station Reporting The control system supports three customer accounts for central station reporting. Each account has its own telephone number and communications options. An explanation of each of these options is included in this section.

  • Page 67: General Options For Central Station Reporting

    10.1.5: Call Attempts The Call Attempts option determines the number of times the system tries to call a telephone number before moving on to the next number in sequence. To program the number of call attempts for an account: From the Programming menu, select Communications, Accounts [951]. Select a CS account (1-3).

  • Page 68: Vocal Message Dialer

    To program the number of Report Cycles: From the Programming menu, select Communications, Accounts, Report Cycles [9518]. Enter a value between 01 and 03. Press when the desired setting is displayed. In the example illustrated in Figure 10.1, Account 1 is programmed with 2 call attempts, Account 2 is programmed with 3 call attempts and the number of report cycles programmed is 3.
  • Page 69 The user presses 1 on their telephone; if there are additional events to report the next message is played. Otherwise, “No Further Messages” is announced. -or- If Two-Way Audio is enabled for the VM account, the user may open the audio channel by pressing 2 on their telephone.

  • Page 70: Remote Programming

    Electronics Line 3000’s Remote Programmer (RP) software enables you to operate and program the system from a PC either on-site or from a remote location. The software provides a comprehensive interface to the infinite prime control system designed to facilitate programming.

  • Page 71: Service Call

    Press when you have finished editing. 10.4.3: RP Communication Interface The infinite prime can employ either cellular or PSTN communication during remote programming. For PSTN communication, the RP uses a double call method so that the line can be shared with regular telephone handsets, an answering machine or fax. The Cellular Communications Module has its own individual telephone number for data transfer and therefore, the double call method is not needed.

  • Page 72: Communications Options

    Enter up to 16 digits. Use the key to enter “*”, “#”, “,” (pause), “T” (switch to DTMF tone dialing), “P” (switch to pulse dialing) or “+” (international code). Use the key to delete one character at a time. Press when you have finished editing.
  • Page 73 Options, PSTN Country [95407]. Select your country from the options available. Electronics Line 3000 offers custom telephone line parameter settings for countries that do not appear in the list of pre-defined options. If your country does not appear among the available options, select the option Custom Settings.
  • Page 74 10.6.8: Dial Tone Wait This option determines whether the system dials only when the dial tone is present or if the dialing is initiated regardless of the dial tone. To program the Dial Tone Wait option: From the Programming menu, select Communications, Comm. Options, Dial Tone Wait [95408].

  • Page 75: Gsm Options

    To program the TWA mode option: From the Programming menu, select Communications, Comm. Options, Two-Way Audio, TWA Mode [95412]. Select Duplex or Simplex. 10.7: GSM Options 10.7.1: GSM RX Report The GSM RX Report is a feature that periodically reads the GSM signal strength of the Cellular Communications module –...
  • Page 76 10.7.3: SMS Center To edit the SMS Center telephone number: From the Programming menu, select Communications, Comm. Options, GSM Options, SMS Center [954133]. Enter up to 16 digits. Use the key to enter “*”, “#”, “,” (pause), “T” (switch to DTMF tone dialing), “P” (switch to pulse dialing) or “+” (international code).

  • Page 77: Twa Event Report Options

    10.8: TWA Event Report Options 10.8.1: TWA Event Report The TWA Event Report is an event report that is sent to the central station to indicate that Two-Way Audio communication is about to commence. If enabled, the system sends the Contact ID event code 606000 before establishing Two-Way Audio communication. This option affects Contact ID only.

  • Page 78: Vocal Message Dialer Event Options

    10.9.2: Restore Reporting For each event group, you can determine whether restore messages shall be sent. To enable/disable restore reporting for an event group. From the Programming menu, select Communications, Event Options [955]. Select an event group. From the event group’s sub-menu, select Report Restore [#2]. Select Enabled or Disabled.
  • Page 79 Transmitter Out of Synch. Control system Transmitter Out of Synch. Supervision Loss Zone Trouble FM Jamming • Arm [#6] Full Arm Part Arm Perimeter Arm • Disarm [#7] Disarm Disarm after Alarm • Water [#8] Zone Water Alarm (Flood) To enable/disable the vocal message for an event group: From the Programming menu, select Communications, VM Event Opt.

  • Page 80: Chapter Eleven: Home Automation Programming

    Chapter Eleven: Home Automation Programming This chapter explains the programmable options for the system’s home automation features. The Home Automation module is an add-on optional extra that you can install inside the control system’s plastic housing. 11.1: X10 Overview The control system’s home automation feature employs the X10 protocol and this enables compatibility with a wide variety of readily available home automation products.
  • Page 81 11.2.2: On by Zone The On by Zone feature allows you to choose two zones that activate the HA unit when triggered. When either one of these zones is triggered, the system sends an On command to the HA unit according to the unit’s programmed Pulse Time – see 11.2.8: Pulse Time.
  • Page 82 11.2.6: Telephone Control Via SMS or DTMF, you can send commands to the system in order to control various HA units. This option allows you to enable or disable this feature for each HA unit. To program the telephone control option for an HA unit: From the Programming menu, select HA Programming, HA Units [961].

  • Page 83: House Code

    11.3: House Code The House code is part of the identification code of each HA unit. For the Home Automation features to function correctly, the House code on each HA unit must be identical to the House code programmed in the system’s memory. To program the system House code: From the Programming menu, select HA Programming, House Code [962].

  • Page 84: Chapter Twelve: System Initialization

    Chapter Twelve: System Initialization The Initialization menu offers a number of options that enable you to reset the system. This menu is particularly useful when re-installing a control system at a new site. The Initialization function clears the entire system. This restores programming defaults, clears the log, user codes and the transmitter register.

  • Page 85: Clear Wireless Transmitters

    12.4: Clear Wireless Transmitters The Clear Wireless Transmitters function enables you to delete all registered transmitters at once. To clear the transmitter register: From the Programming menu, select Initialize, Clear Wireless [974]; the system prompts you for confirmation. Press to confirm; the transmitter register is cleared. 12.5: Find Modules The Find Modules function runs a diagnostic test that identifies the modules and keypads that are connected to the system bus.

  • Page 86: Appendix A: Menu Structure

    Appendix A: Menu Structure Legend: Installer code required Master code required -86-...
  • Page 87 -87-...
  • Page 88 -88-...
  • Page 89 -89-...
  • Page 90 -90-...
  • Page 91 -91-...
  • Page 92 -92-...

  • Page 93: Appendix B: Transmitter Installation

    The EL-2600, EL-2600PI, EL-2645 and EL-2645PI are intelligent wireless PIR sensors for use with the infinite prime system. All of these sensors implement a feature to combat the problem of multiple transmissions, which drastically reduce the life of the batteries. After each transmission, there is a four-minute delay during which further transmissions will not be sent.
  • Page 94 For maximum pet immunity the following guidelines are recommended: • Mount the center of the unit at a height of 2m with the PCB vertical setting at -4. • Set the pulse counter to 2. • Do not aim the detector at stairways that can be climbed by an animal. •...
  • Page 95 Vertical Adjustment To position the PCB, turn the Easy Lock counter-clockwise and slide the PCB up or down to the required setting using the vertical adjustment scale. The detector’s coverage area is 14m x 14m (EL-2600/EL-2645) or 12m x 12m (EL-2600PI/EL-2645PI) when the PCB is positioned at 0.

  • Page 96: Magnetic Contact (El-2601)

    Figure B.2: Lens Coverage Diagrams EL-2600/EL-2645 (left) and EL-2600PI/EL-2645PI (right) Magnetic Contact (EL-2601) The EL-2601 is a magnetic contact designed for installation on doors and windows. Antenna Installation Procedure To install magnetic contacts. To open the housing, insert a small Indicator screwdriver at the bottom of the unit between the front and back cover and...

  • Page 97: Universal Transmitter (El-2602)

    To remove the PCB, press the PCB release tab and carefully lift the board and slide the board away from the back cover. The EL-2601 is able to operate in Jumper Position Operation Mode three modes: Magnetic Switch, Pins 1&2 Universal Transmitter Universal Transmitter or a combination Pins 2&3...

  • Page 98: Glassbreak Sensor (El-2606)

    After registration, press the EL-2602’s tamper switch to terminate Test mode. Before permanently mounting the unit, test the transmitter from the exact mounting position. To remove the PCB, press the PCB release tab, carefully lift the board and slide the board away from the back cover. When handling the PCB, do not apply pressure on the antenna.
  • Page 99 • Avoid installing rooms with lined, insulating sound deadening drapes. • Avoid installing in rooms with closed wooden window shutters inside. • Avoid installing in the corners of a room. The EL-2606 is best suited to rooms with moderate noise. The sensor may not consistently detect cracks in the glass, bullets which break through the glass or glass breaking around corners and in other rooms.
  • Page 100 In Normal mode, the tester will not activate the sensor unless held directly over the sensor. Test the sensor using the Electronics Line GBS7 or Sentrol 5709C hand-held tester. If using the 5709C tester, set the tester to tempered glass. The 5709C tester has a different setting for each type of glass.

  • Page 101: Smoke Detector (El-2603)

    To perform a Hand Clap test: Clap your hands loudly under the sensor; the LED flashes twice but an alarm is not generated. Smoke Detector (EL-2603) The EL-2603 is a brand-name smoke detector with an integrated Electronics Line 3000 transmitter. Installation Procedure The following procedure explains the installation of the EL-2603 wireless smoke detector and its registration to the receiver.

  • Page 102: Keyfobs (El-2611/El-2614/El-2614E)

    Select the zone to which you want to Opening register the transmitter; the system initiates Registration mode. When Save? appears control system’s LCD display, press After registration, remove the Test jumper and place it over one pin for storage. Before permanently mounting the unit, test the transmitter from the exact mounting position.

  • Page 103: Wireless Keypads (El-2620/El-2640)

    To replace the batteries: Insert a small screwdriver into the pry-off slot – see Figure B.12 Carefully twist the screwdriver to separate the front and back of the casing. Observing correct polarity, replace the batterie(s) (2 3V lithium, size: CR1225 for EL-2614 and 3V lithium, size CR2032 for EL-2614E)..
  • Page 104 9V Alkaline Battery Tamper Switch Buzzer Figure B.15: EL-2620 (back cover off) Battery Replacement (EL-2640) When the battery is low, the EL-2640’s LED flashes during transmission. To replace the battery: Remove the battery cover located at the rear of the unit. To do so, press the release tab using a small screwdriver and lift the cover away from the EL-2640’s plastic housing.

  • Page 105: Transmitter Specifications

    Transmitter Specifications The technical specifications for the transmitters that appear in this appendix are listed below. All transmitters are available in 868.35, 433.92 or 418MHz FM frequencies. EL-2600 EL-2645PI Antenna: Built-in Whip Antenna: Built-in Whip Power: 3.6V ½ AA Lithium Battery Power: 3.6V ½...
  • Page 106 EL-2611 EL-2620 Antenna: Built-in Whip Antenna: Printed on PCB Power: Non-replaceable battery Current Consumption: 26mA (transmission) RFI Immunity: 40V/m 2µA (standby) Operating Temperature: 0 to 60°C Power: 9V Alkaline Battery Dimensions: 60 x 40 x 15mm RFI Immunity: 40V/m Operating Temperature: 0 to 60°C EL-2614/EL-2614E Dimensions: 130 x 110 x 28mm Antenna: Built-in Whip...

  • Page 107: Appendix C: Event Table

    Appendix C: Event Table Burglary Description Restore Contact ID Address Field Alarm from Zone 1130 Device Number Zone Alarm Restore 3130 Device Number Zone Bypassed 1570 Device Number Zone Unbypassed 3570 Device Number Zone Tamper 1137 Device Number Zone Tamper Restore 3137 Device Number Zone Panic Alarm...
  • Page 108 Power Description Restore Contact ID Address Field Battery Low 1302 Device Number Battery Restore 3302 Device Number Transmitter Low Battery 1384 Device Number Transmitter Battery Restore 3384 Device Number AC Loss 1301 Device Number AC Restore 3301 Device Number Peripherals Media Loss 1351 Device Number...

  • Page 109: Appendix D: Zone Types

    Appendix D: Zone Types Normal A Normal zone is active when the system is armed. This zone generates a Burglary alarm instantly when triggered. Normal zones are designed for detectors installed inside the protected site or doors/windows that are never used to enter the premises. Event Group: Burglary Entry/Exit When the system is armed, Entry/Exit zones initiates the entry delay when triggered.
  • Page 110 24Hr-X The 24Hr-X zone is a future option that is not available in the current firmware. Event Group: Not applicable Gas zones are always active. In the event of a gas leak, these zones generate a Gas alarm. Gas zones are typically used with methane/propane/butane or carbon monoxide gas detectors.
  • Page 111 ELECTRONICS LINE 3000 Ltd. - LIMITED WARRANTY ELECTRONICS LINE 3000 Ltd. (hereafter “EL3K”) warrants its products to be free from manufacturing defects in materials and workmanship for (Wireless – 12 months excluding batteries, Control systems – 2 years, Dual Technology Detectors – 2 Years, PIR Detectors - 5 years) following the date of sale. EL3K will, within said period, at its option and in accordance with the terms of this Limited Warranty, repair or replace any product failing to operate correctly without charge to the original purchaser or user.
  • Page 113 Copyright © 2008 Electronics Line 3000 Ltd. All rights reserved.
