3.2.

Front Panel System Status LEDs

The two LEDs, OK and Arm Status, provide essential information on the status of the system.
Table 3-1: OK LED Indication
OK LED Status
Off
Green On
Green Flashing
Yellow On
Yellow Flashing (slow)
Yellow Flashing (fast)
Yellow Intermittent
On/Off
Table 3-2: Arm Status LED Indication
LED Status
Off
Green On
Red Flashing
Alarm indication is not displayed after a silent panic alarm.
3.3.

Front Panel Keypad

The alphanumeric keypad on the front panel enables you to perform various operation and
programming tasks. Apart from Full, Part, and Perimeter arming, the front panel keypad offers a
number of special functions.
Table 3-3: Front Panel Keypad Functions
Key
14
görünmesini istediğiniz metne Heading 1 uygulamak için Giriş sekmesini kullanın.
Meaning
Both AC and Battery power are disconnected.
System Power Status is OK and there is no System Trouble.
Open Zone. Check that the windows and doors are closed and no movement is
detected by the detectors within the protected area.
System Trouble.
Backup battery low or low battery from transmitters.
AC loss.
System Trouble in addition to AC loss/Low Battery.
Meaning
The system is disarmed.
The system is armed.
An alarm has occurred. Alarm indication is cleared the next time you arm the
system or view the relevant arming event in the event log.
Symbol used in Special function
the text of this
manual
1 Used to enter symbols in descriptor editing.
0 Used to enter symbols in descriptor editing.
Χ Used to cancel the current selection.
Used to return to the previous menu level.
√ Used to enter Menu mode.
Used to select the current menu item.
Used to signify the end of an entered value.
Toggles status in Zone Bypass/Unbypass function.
