Appendix B: Transmitter Installation

Keyfobs (EL-2711M / EL-2711P / EL-2614E and EL-2714)

The EL‐2711M, EL‐2711P, EL‐2614E and EL‐2714 are keyfob transmitters that are all supported by
the system.
Figure B- 31: EL-2711M/P
Registration Procedure
To register keyfobs:
1. From the Programming menu, select Devices, Keyfobs [912].
2. Select the keyfob you want to register; the system initiates Registration mode.
3. Press a button, making sure that the keyfob's LED lights up when the button is pressed.
4. Press the same button again. When Save? appears on the Control System's LCD display,
press ʹ√ʹ.
EL-2711M
The EL‐2711M is a one‐button transmitter that generates a Medical alarm when pressed. The
transmitter is water resistant and can be worn around the neck. Its large button makes it ideal for
elderly or sight‐impaired users.
When the battery is low, the EL‐2711M's LED flashes during transmission and a Low Battery signal is
sent to the receiver. When either of these two indications is observed, replace the unit.
EL‐2711M complies with EN‐50131 Grade 2 Class II Power Supply Type C.
EL-2711P
The EL‐2711P is a one‐button transmitter that generates a Panic alarm when pressed. The
transmitter is water resistant and can be worn around the neck. Its large button makes it ideal for
elderly or sight‐impaired users.
When the battery is low, the EL‐2711P's LED flashes during transmission and a Low Battery signal is
sent to the receiver. When either of these two indications is observed, replace the unit.
EL‐2711P complies with EN‐50131 Grade 2 Class II Power Supply Type C.
CommPact Installation Manual
Figure B- 32: EL-2714 Figure B- 33: Opening the EL-
2714's Casing
