3. Open the SIM card holder on the Main Board; insert the SIM card
4. Close the Housing.
5. Plug the Power AC cable into the wall outlet.
In five minutes since power‐up, the siren will sound. To silence the siren, press your user
code (default user code is 1234).
At this stage, do not connect the backup battery. Ignore any trouble conditions that
may appear on the LCD Display (e.g. Low Battery).
Figure 2-5: Main Board Wiring Scheme
2.2.2. Stage 2: Selecting Language and Defaults
The Control System supports several languages. Language and defaults settings must be defined
before any configuration parameters are set or any transmitters registered.
Setting language and defaults automatically initializes the Control System. This means that
all prior configuration settings are reset to the default settings and all previously registered
transmitters are deleted from the Control System.
To select language and defaults:
1. Press ʹ√ʹ.
2. Enter your Installer code (the default Installer code is 1111).
3. From the Programming menu, select Devices [971].
4. Select default and press ʹ√ʹ.
5. Select language (Voice + LCD display) and press ʹ√ʹ.
6. Press ʹ√ʹ once more to initialize the Control System
2.2.3. Stage 3 – Register the Transmitters
For the Control System to recognize a device, its transmitter must be registered. In general terms,
transmitter registration means sending two transmissions from a device when the Control System is
in Registration mode.
To register a device:
1. Press ʹ√ʹ.
2. Enter your Installer code.
3. From the Programming menu, select Devices [91].
4. Select the type of transmitter you want to register. For example, if you want to register a
wireless detector to a zone, select Zones.
*
optional feature
CommPact Installation Manual
* (see p. 5, Figure 1‐2 ).
