Appendix B: Transmitter Installation
Installation Instructions
1. Open the housing. To do so, remove the cover screw located at the bottom of the housing
and lift the front cover away from the rear housing.
2. Remove the strobe cover. To do so, carefully lift the bottom of the strobe cover away
from the rear housing and remove it from the strobe cover holding hooks.
3. Using a Phillips screwdriver, remove the two screws that secure the metal anti‐vandal
casing and lift the casing from the back cover of the siren.
4. Connect a 12VDC or 9VAC, 500mA transformer to terminals 3 and 4 on the siren's
terminal block (polarity is not important) – see Figure B‐ 50.
Figure B- 50: Wiring Connections
Power down the control system before plugging in the on‐board transmitter.
5. On the control system, define the siren type as "2‐Way Siren" as follows:
From the Programming menu, select Devices, Siren, Ext. Siren Type [9152].
o
Select "2‐Way Siren".
o
6. Define the Siren Cut‐off as follows:
From the Programming menu, select Devices, Siren, Cut‐Off [9154].
o
Enter a siren cut‐off time (00:10 ‐ 20:00 minutes).
o
7. Set the siren to Registration mode by placing the Mode jumper (JP1) as shown in Figure
B‐ 51.
8. Press the Transmitter Delete button on the siren in order to clear the siren's register; the
siren sounds an acknowledge tone.
9. O n the control system, perform the External Siren Test twice in order to register the
control system's transmitter to the EL‐2626AC's receiver.
To perform an External Siren Test:
From the Service menu, from the Service menu, select WL. Siren Test [703] or Ext.
o
Siren Test [702], depending on your control system model; the siren sounds an
acknowledge tone when each transmission is received.
During the registration procedure, make certain that no other wireless devices are
transmitting so as not to interfere with registration. In the event that the wrong transmitter
is registered to the siren's receiver, you can delete the transmitter by pressing the
Transmitter Delete button while the Mode jumper is set to Registration mode.
CommPact Installation Manual
Terminals 1 & 2: External Tamper Input
Terminals 3 & 4: Power Input
Terminals 5 & 6: Siren Output
Terminals 7 & 8: Back Tamper Input
