9 System Options
To program the Supervision Loss Indication setting:
1. From the Programming menu, select System Options, Display, SV Loss Ind. [94064].
2. Select Enabled or Disabled.
9.7.

PGM Output Options

PGM (1-2) and are programmable outputs that are triggered according to specific system status conditions, or by
remote command sent via PSTN, GSM, keyfob, keypad, or RP.
9.7.1. Output Trigger
The Output Trigger option determines the conditions that activate and deactivate the PGM output.
To program the Output Trigger:
1. From the Programming menu, select System Options, PGM Options [9407].
2. Select a PGM Output.
3. Select Output Trigger [#1].
4. Select an Output Trigger option from the following table.
Table 9-1: PGM Output Trigger Options
Trigger Option
PGM Not Used
Full Arm
Perimeter Arm
Part Arm
Arm Status
Power Trouble
Tel. Line
Trouble
System Trouble
Medical
Burglary
Fire Alarm
Zone Status
*
Entry/Exit
Siren
WL Siren
Telecontrol
For certain trigger options, deactivation may be determined by the PGM Cut-off -- see p. 50,
9.7.4 PGM Cut-off. If the PGM Cut-off is programmed as 000 (continuous activation), the
PGM output shall remain activated until it is toggled by the relevant change in system
status.
9.7.2. Output Type
The Output Type option determines whether the PGM output produces a steady or pulsed output.
To program the Output Type:
1. From the Programming menu, select System Options, PGM Options [9407].
2. Select a PGM Output.
3. Select Output Type [#2].
4. Select Steady or Pulsed.
The Zone Status, Siren and WL Siren trigger options have a fixed Output Type; there is no
need to program an Output Type for these options.
Zone Status functions only when the system is disarmed.
*
iConnect Installation Manual
Activated by...
The PGM output is disabled
System "Full" armed
System "Perimeter" armed
System "Part" armed
Any arming method
AC Loss or Low Battery conditions
Telephone line supervision trouble
System trouble condition
Medical alarm
Burglary alarm
Fire alarm
Open zones (steady)
Bypassed zones (pulsing)
Entry/Exit delay follower
Built-in siren follower
Wireless siren follower
Remote PGM activation (PSTN/GSM/keyfob/keypad/RP,
321 and above
)
Deactivated by...
System disarmed or PGM Cut-off
AC restore or Battery restore
Telephone line restore
System trouble restore
Any arming method, system disarmed or
PGM Cut-off
All zones closed and no zones bypassed
or via Internet in ELAS versions
49
