Appendix B: Transmitter Installation
approach at 22 (+/‐ 0.5) mm.
7. To remove the PCB, press the PCB release tab and carefully lift the board and slide the
board away from the back cover.
When handling the PCB, do not apply pressure on the antenna.
8. The EL‐2601 is able to operate in two modes: Magnetic Switch or Universal Transmitter.
If connecting a wired contact loop (N.C.), connect the terminal block as follows: 1 ‐
Alarm; 2 ‐ GND. For this purpose, a wiring knockout is provided in the back cover.
9. If using the Back Tamper switch, insert a screw into the Back Tamper mounting hole
located in the center of the back cover – see p. 100, Figure B‐ 16. When the detector is
removed from the wall, the screw causes the tamper release to break away from the back
cover and the Back Tamper switch is released.
10. Mount the back cover using two screws and replace the PCB. Use ISO 7050 (ST3.5 x 22),
#6 X ¾ or similar countersunk screws so that the screw head will not touch the PCB – see
p.100, Figure B‐ 15.
11. To open the magnet's housing, insert a small screwdriver into one of the pry‐off slots
located at either end of the magnet's back cover and lift to separate from the front cover.
12. Mount the back cover of the magnet using two screws. Make sure that the guideline on the
magnet is correctly aligned with the guideline on the transmitter.
Do not install the magnet further than 1cm (0.4ʺ) from the transmitter.
13. Test the transmitter, making certain that the LED is lit when opening the door/window
and again when closing.
14. Close the front covers of the transmitter and the magnet.
EL‐2601 complies with EN‐50131 2‐6 Grade 2 Class II Power Supply Type C
