Appendix B: Transmitter Installation
Testing Your Smoke Detector
To be sure that detector is working correctly test the detector weekly by performing the following
procedure:
Use your finger to firmly press the test button. If the detector is functioning correctly, the alarm
horn sounds. To stop the alarm horn, press the test button again. If the detector fails to test
properly, have it repaired or replaced immediately.
If the alarm horn begins to beep once every 35 seconds, it means that the detector's batteries are
weak. Replace the batteries immediately. Keep fresh batteries on hand for this purpose.
Figure B- 30: Testing the Smoke Detector
Cooking smoke or a dusty furnace (sometimes called "friendly fires" (can cause the alarm
to sound. If this happens, open a window or fan the air to remove the smoke or dust. The
alarm will turn off as soon as the air is completely clear. Do not disconnect the batteries
from the detector. This will cancel your protection from fire.
Taking Care of Your Smoke Detector
To keep your detector in good working condition, you must test the detector weekly, according to
the "Testing Your Smoke Detector" section.
Cleaning the Smoke Detector
1. Clean the housing with a dry or damp cloth to remove dust and dirt. If necessary, open
the smoke chamber and clean the interior of the detector.
2. Remove the detector from the detector base.
3. Remove the batteries.
4. Using a flat screwdriver release the smoke detector cover.
5. Using a flat screwdriver lift the smoke chamber housing slightly.
6. Use a fine paintbrush to remove dirt from the chamber.
7. After cleaning, close the smoke chamber, fix the housing and remount the detector on the
ceiling.
Do not forget to change the batteries!
CommPact Installation Manual
Buzzer
Openings
Test / Silence
Button
LED Indicator (Red)
Detector
