Partial Output - Microscan MS-7100 User Manual

Chapter 2 Menu Configuration

Partial Output

Status
Default: Disabled
Options: Disabled, Enabled
When enabled, allows you to pre-select portions of labels to be transmitted
by the scanner.
In multilabel mode, partial output is performed on each separate label. For
example, if Start Position is set to 3 and Partial Length is set to 5, the follow-
ing labels are transmitted as follows:
1234567890 as
1234 as
1234,abcde as
12 as
Start Position
Default: 1
Options: 1 to 63
Allows you to determine the first character from the beginning of a label to
transmit.
Partial Length
Default: 63
Options: 1 to 63
Allows you to determine the number of characters to be transmitted.
2-36
MS-7100/7180 Industrial Scanner User's Manual
"34567"
"34"
"34,cde" (two labels with separator)
""
