Table A-5 Bios Specifications; Table A-6 Bios Hotkey List - Silicon Graphics SGI 1100 Maintenance And Upgrade Manual

007-4047-001
Table A-5 provides details about the BIOS.
BIOS Specifications
Table A-5
Item
BIOS version
BIOS ROM type
BIOS ROM size
BIOS ROM package
Supported protocol
Boot from CD-ROM feature
Supports LS-120 drive
Supports BIOS boot block
feature
BIOS password control
SGI logo display control
during POST
Note: The BIOS can be overwritten or upgraded using the AFLASH utility
(AFLASH.EXE), as described in Appendix B on page 133.
Table A-6 provides details about the hotkeys.
Table A-6 BIOS Hotkey List
Hotkey Function
Ctrl-Alt-Esc Enter BIOS Setup Utility.
Hardware Specifications and Configurations
Specification
A1 S4 or higher
Bulk mode flash ROM with boot block protection
512 KB
32-pin PLCC package
PCI 2.2, APM 1.2, VESA/DPMS (VBE/PM V1.0), DMI 2.03,
E-IDE 1.1, ACPI 1.0, ESCD 1.03, PnP 1.0a, bootable CD-ROM 1.0,
USB 1.0, UHCI 1.0, PC97-compliant, ANSI ATA 3.0, ATAPI
Yes
No
Yes
Check/bypass with JP8 setting
Enable/disable with JP7 setting
Description
Press the hotkey while the system is
booting to enter BIOS Setup Utility.
123
