2: Removing and Replacing System Components
74
6. Remove the plastic plenum by separating it from the power supply module and
gently detaching it from the power socket module, as shown in Figure 2-43.
Note: The plastic plenum adheres to the sides of the power socket module. Proceed
with care to free the plenum from the power socket module.
Plenum
Figure 2-43 Removing the Plastic Plenum
007-4047-001
