Figure 2-35 Securing The Cd-Rom Drive To The Drive Module - Silicon Graphics SGI 1100 Maintenance And Upgrade Manual

007-4047-001
4. Follow these steps to tighten the two screws on the other side of the drive module:
– Hold the drive module vertically with the two empty screw holes pointing
down as shown in Figure 2-35.
– Place a screw on the tip of a small Phillips screwdriver as shown in Figure 2-35.
Note: If the type of Phillips screwdriver you are using does not allow a screw to
stay balanced on the tip of the screwdriver, see step 5 for an alternative
procedure.
– Pass the screw through the drive module opening and tighten the screw.
– Repeat this procedure for the other screw.
Securing the CD-ROM drive to the Drive Module
Figure 2-35
Replacing Removable-Media Devices
Screw balanced
on tip of screwdriver
61
