Features Summary

007-4047-001
The system has the following major components:
• Processor
Supports dual Pentium III processors installed in a socket 370 running a 133-MHz
Front Side Bus (FSB).
• Chipset
ServerWorks ServerSet III LE chipset consists of CNB30LE (Champ North Bridge)
and OSB4 (Open South Bridge) is in charge of the host interfacing, memory system
control, PCI interfacing, and data steering.
• LAN controller
Two on-board Intel 82559 10/100-Mb/s PCI LAN controllers.
• Memory
The CNB30LE champ north bridge consists of a system memory controller
integrated with four DIMM sockets that support 128-, 512- and 1024-MB (in the
future) registered ECC SDRAM DIMMs with a maximum memory upgrade of 4 GB
(1024 MB x 4 DIMM modules).
• Cache
256-KB second-level write-back PipeLined-Burst SRAM supported cache on
Pentium III processor.
• Video
On board PCI VGA controller (ATI Rage XL) with 4-MB SDRAM graphics memory
support.
• BIOS
– 512-KB Flash ROM built-in 28SF040A-90 for system and IPMI BIOS.
– Y2K NSTL-compliant.
•
Real-time clock (RTC)
– 256-byte battery-backed CMOS RAM.
– Built-in SMC FDC37B787 super I/O controller.
– System clock/calendar with battery backup.
•
Power supply
Standard 200W power supply.
