Chapter 1
1.
Chassis Description
The SGI 1100 server is a 1U, high-density, rackmountable, PCI bus-based dual-processor
system built on an extended ATX baseboard. It comes with two socket 370 processor
sockets utilizing one or two Intel Pentium III processors integrated with the Server
Works LE north and OSB4 south bridge chipsets. The system board integrates two Intel
82559 10/100 Mbps PCI Ethernet chipsets that supports WOL (wake on LAN) for better
remote site management.
For expandability, the system includes one 64-bit/66-MHz PCI bus slot and four DIMM
slots that allow memory installation to a maximum of 2 GB using four 512-MB SDRAM
(synchronous DRAM) DIMMs.
For connectivity, the system supports four USB (Universal Serial Bus) connectors, a video
port, two LAN ports, and other standard features such as two serial ports, a diskette
drive interface, and two embedded IDE hard disk interfaces.
The system is fully compatible with Redhat Linux 6.2, Windows NT 4.0, and Windows
2000 Advanced Server OS.
This chapter contains a detailed description of the SGI 1100 server system components.
007-4047-001
1
