Removing a DIMM

007-4047-001
Follow these steps to remove a DIMM:
1. Remove the chassis cover as described in "Removing the Chassis Cover" on
page 21.
2. Press the retaining clips on both sides of the socket outward to release the DIMM, as
shown in Figure 2-52.
Note: To gently disengage the DIMM from the socket, place your fingers on the top
of the DIMM before you press the retaining clips.
Caution: The DIMM closest to the processors (DIMM 1) may touch the processor fan
cages during the removal of the DIMM. Proceed carefully, do not apply excessive
lateral pressure on the DIMM socket.
3. Install the chassis cover as described in "Installing the Chassis Cover" on page 23.
