Rear Panel I/O Ports and Features

007-4047-001
This section describes the rear panel I/O ports and other features, as shown in Figure 1-3.
Figure 1-3 Rear Panel I/O Ports and Features
Table 1-2 describes the rear panel I/O ports and features that are indicated in Figure 1-3.
Rear Panel I/O Ports and Features
Table 1-2
No. Item
1 AC power input
2 Ventilation
3 Serial port 2
4 PS/2 mouse port
5 Ventilation
6 Ventilation
7 Add-on card bracket
8 LAN 2 port (RJ-45)
9 LAN 1 port (RJ-45)
10 USB ports (2 ports)
11 VGA port
