A: Technical Specifications

Hardware Specifications and Configurations

122
Table A-3 lists the major chips on the system board.
Table A-3 Major Chips on System Board
Item
System core logic
Super I/O controller
LAN controller
Memory controller
VGA controller
E-IDE controller
Keyboard controller
RTC
Table A-4 provides details about the processor.
Processor Specifications
Table A-4
Item Specification
Type Dual Intel Pentium III processor in Flip Chip Pin Grid Array (FC-PGA)
package
Socket Socket 370
Speed 800 or 1000 MHz
Bus frequency 133 MHz
Voltage Processor voltage is automatically detected by the system with no jumpers
Controller
ServerWorks ServerSet III LE Chipset (CNB30LE/OSB4)
SMC FDC37B787
Intel 82559
Built-in ServerWorks CNB30LE (Champ North Bridge)
ATI Rage XL
Built-in ServerWorks OSB4 (Open South Bridge)
Built-in SMC FDC37B787 Super I/O controller
Built-in SMC FDC37B787 super I/O controller
007-4047-001
