Replacing the Link Bar and the Riser Card
Removing the Link Bar
007-4047-001
This section covers the removal and installation of the link bar and the riser card.
Follow these steps to remove the link bar:
1.
Remove the chassis cover as described in "Removing the Chassis Cover" on
page 21.
2. Remove two screws from the rear panel and pull the link bar away from the chassis
as shown in Figure 2-4.
Replacing the Link Bar and the Riser Card
25
