2: Removing and Replacing System Components

Replacing the Intrusion Alert Microswitch Cable Module

48
Follow these steps to remove the intrusion alert microswitch cable module:
1. Remove the chassis cover as described in "Removing the Chassis Cover" on
page 21.
2. Disconnect the intrusion alert microswitch cable connector from the system board.
See Figure 2-23 for the location of the intrusion alert microswitch cable connector.
Microswitch cable
connector
Microswitch
Figure 2-23 Location of the Intrusion Alert Microswitch Cable Connector
007-4047-001
