Replacing the Rear Chassis Blowers
Removing a Rear Chassis Blower
007-4047-001
This section covers the removal and installation of the rear chassis blowers.
Follow these steps to remove the rear chassis blowers:
1.
Remove the chassis cover as described in "Removing the Chassis Cover" on
page 21.
2. Release two screws to remove the blower as shown in Figure 2-14.
3. Disconnect the blower cables from the connectors on the system board. See
Figure 2-13 for the location of the rear chassis blower cable connectors.
Replacing the Rear Chassis Blowers
37
