A: Technical Specifications
126
Table A-11 details the LAN interface specifications.
LAN Interface Specifications
Table A-11
Item
LAN controller
LAN controller resident bus
LAN port
Function control
Table A-12 details the VGA interface specifications.
Table A-12 VGA Interface Specifications
Item
VGA controller
VGA controller resident bus
VGA memory
Table A-13 details the IDE specifications.
Table A-13 IDE Interface Specifications
Item
IDE controller
IDE controller resident bus
Number of IDE channel
Supported IDE interface
Supports LS-120
Supports bootable CD-ROM
Function control
Specification
2 Intel 82559 LAN controllers
PCI bus
2 RJ-45 on board (CN16/CN17)
Enable/disable by BIOS setup
Specification
ATI Rage XL
PCI bus
4-MB SDRAM
Specification
Built-in RCC OSB4 (Open South Bridge)
PCI bus
2 (CN 21, CN 27)
E-IDE (up to PIO mode 4, DMA mode 2 and Ultra DMA-33),
ANSIS ATA rev. 3.0, ATAPI
No
Yes
Enable/disable by BIOS setup
007-4047-001
