007-4047-001
5. Install the metal air guide plate and secure it with two screws as shown in
Figure 2-47.
Note: Ensure that all cables fit within the metal air guide plate opening, so that no
cables are stuck between the air guide plate and the chassis.
Air guide plate
Figure 2-47 Installing the Metal Air Guide Plate
Replacing the Power Supply Module
79
