System Chipsets

Server Works LE North and South Bridge

LAN Subsystem

Video Subsystem

Expansion Slot

007-4047-001
The Server Works LE north chipset incorporated as a north bridge is in charge of the host
bus interfacing and memory bus control. The memory bus control supports PC-133
SDRAM registered ECC DIMMs up to a total of 4 GB. The north bridge provides one
64-bit PCI bus running at 66 MHz.
The south bridge subset provides the legacy ISA interface, USB port, ATA33, and System
Management Bus (SMB). The BMC (Baseboard Management Control) was embedded on
the motherboard and connected with the south bridge to provide the ASM and RDM
functions and industry standard IPMI protocol.
Another cost-effective feature for network solution is the integration of Intel's 82559
10/100 Mbps Fast Ethernet controller which supports Advanced Configuration and
Power Interface (ACPI) 1.20A-based power management, wake on Magic Packet, wake
on interesting packet, advanced SMB-based manageability, Wired for Management
(WfM) 2.0 compliance, IP checksum assist, PCI 2.2 compliance, and PC 98 and PC 99
compliance.
The ATI Rage XL harbors 2D and 3D display capabilities that bring life to any multimedia
and work applications. It also supports hardware DVD decoding. With remarkable color
depths and high resolutions of up to 1600x1200, it enhances every visual experience on
your system.
The on-board ATI Rage XL chipset comes with 4 MB of video memory.
The system board has one 64-bit/66-MHz PCI bus slot with a riser card.
System Chipsets
3
