Silicon Graphics SGI 1100 Maintenance And Upgrade Manual page 111

007-4047-001
3. Connect all cables to the system board. See "Jumper and Connector Information" on
page 117 for the location of all connectors.
Note: The diskette drive signal cable is delicate. To connect the diskette drive signal
cable to the diskette drive connector, follow the steps shown in "Installing the
Diskette Drive/CD-ROM Drive Module" on page 54
4. Install the two rear system blowers as described in "Installing a Rear System
Blower" on page 39.
5. Install the link bar, as described in "Installing the Link Bar" on page 27.
6. Install the chassis cover as described in "Installing the Chassis Cover" on page 23.
Replacing the System Board
95
