Table A-2 System Board Layout - Silicon Graphics SGI 1100 Maintenance And Upgrade Manual

A: Technical Specifications
118
Note: Jumpers have the "JP" prefix. Connectors have the "CN" prefix.
Table A-2 describes the items shown in Figure A-1.
Note: Settings in boldface are the default settings.
Table A-2 System Board Layout
Item
BT1
BU1
CN1, CN6, CN36
CN3
CN4
CN5
CN7
CN8
CN10
CN13, CN19, CN20, CN23,
CN28
CN14
CN15
CN16
CN17
CN18
CN21
Description
Battery
Buzzer
IPMI connectors
ATX power supply connector
Upper: PS/2 mouse connector
Lower: PS/2 keyboard connector
Serial port connector
CPU 1 thermal connector
CPU 1 fan connector
Left: Serial 1 port
Right: VGA port
Housing fan and blower connectors
USB 1 and USB 2 connectors
LED/switchboard connector (see Figure A-2 on page 121)
LAN 1 jack (RJ45)
LAN 2 jack (RJ45)
NMI switch
Primary IDE connector
