007-4047-001
7. Plug the fan/heatsink cables to the system board. See Figure 2-50 for the location of
the fan/heatsink cable connectors.
Fan/heatsink cable
connector
5 V
Figure 2-50
Location of the Fan/Heatsink Cable Connector
8. Install the chassis cover as described in "Installing the Chassis Cover" on page 23.
V
3 . 3
Installing a Processor
Fan/heatsink cable
connector
85
