C.
007-4047-001
Appendix C

Port Pinouts

This Appendix contains port pinout information for the following ports:
• "PS/2 Keyboard Port" on page 136
• "PS/2 Mouse Port" on page 137
• "VGA Port (DB15 HD)" on page 138
• "Serial Ports" on page 139
• "USB Ports" on page 140
• "Ethernet Ports (RJ45)" on page 141
135
