A: Technical Specifications
132
Table A-19 (continued)
PCI Devices
INTA#
LAN 2
PIRQ10
VGA
PIRQ0
Table A-20 lists the PCI devices interrupt routing for each PCI slot.
Table A-20
PCI Interrupt Routing 2
PCI Devices
INTA#
Slot 1
INTIN5/APIC2
LAN 1
INTIN1/APIC2
LAN 2
INTIN10/APIC2
VGA
INTIN0/APIC2
Table A-21 lists the on-board device IDs and IRQs.
Table A-21
On-board Device ID & IRQ Map Table
Device
AD
LAN 1
AD27
PCI slot 1
SAD23
VGA
AD29
LAN 2
AD28
PCI Interrupt Routing 1
INTB#
INTB#
INTIN11/APIC2
IDSEL
14h
7h
0Dh
0Ch
INTC#
INTD#
INTC#
INTD#
INTIN13/APIC2
INTIN15/APIC2
007-4047-001
