Raise retaining latch
1
007-4047-001
Insert cable
2
CD-ROM drive
data cable connector
Figure 2-29 Connecting the Drive Module Signal Cables
5. Secure the signal cable retaining strap.
6. Install the link bar, as described in "Installing the Link Bar" on page 27.
7. Install the chassis cover as described in "Installing the Chassis Cover" on page 23.
Replacing Removable-Media Devices
Lower retaining latch
3
Diskette drive
data cable
55
