To:
• Zoom in, click on the magnifying glass icon with the + sign above
the upper right corner of the memory map window.
• Zoom out, click on the magnifying glass icon with the - sign above
the upper right corner of the memory map window.
• Exit zoom mode, click on the magnifying glass icon with the "x"
above the upper right corner of the memory map window.
• View a memory object by itself by double-clicking on the memory
object.
• View the memory object containing the current memory object by
double-clicking on the white space around the memory object
Figure 4-24. Memory Map – Zoom Options

Inserting a Gap into a Memory Segment

A gap may be inserted into a memory segment in the graphical memory
map.
To insert a gap:
1. Right-click on a memory segment.
2. Choose Insert gap. The Insert Gap dialog box appears, as shown in
Figure 4-25.
