CDM-700 High Speed Satellite Modem
Front Panel Operation
Demod: Not Locked
Press or
ENTER
Monitor:
Stored Events:
Clear-All
Select View or Clear-All using the
If View is selected:
Log000 09/02/07 12:29:11
Info–Power Off
Scroll backwards or forwards through the entries in the event log, using the
The event log can store up to 255 events. When a fault condition occurs, it is time-stamped and
put into the log. Similarly, when the fault condition clears, this also is recorded.
IMPORTANT
Press or
ENTER
If Clear-All is selected, the prompt occurs:
Clear All Stored Events:
No
If Yes is selected, the event log is cleared, and the previous menu returns. However, if there are
faults present on the unit at this time, they will be re-time-stamped, and new log entries will be
generated.
Select No or Yes using the
RSL=-+00
to return to the previous menu.
CLEAR
Event-Log
◄ ►
(
Note that, in accordance with international convention, the date is shown in
DAY-MONTH-YEAR format.
to return to the previous menu.
CLEAR
Yes
◄ ►
arrow keys. Press
View
( E)
arrow keys. Press
E)
( E)
.
ENTER
6–57
MN/CDM700.IOM
.
ENTER
arrow keys.
▲ ▼
Revision 5
