is screen displays as long as the infusion is running. Notice the information on each eld:
1. e rst line displays the rate of the infusion in whichever units/hour has been selected.
information toggles with the programmed "Amount To Be Infused."
2. e second line displays a graphic bar representing the percentage of the completed infusion.
e graphic bar will toggle with Line Pressure ("L Press") which displays the current
patient side (downstream) pressure in the administration set in millimeter of mercury
(mmHg) units.
3. e third line displays the "Total Volume Infused" and, if mg or mcg is the selected unit, this
eld will toggle to display the total (mg or mcg) infused as well.
4. e last line displays the "Remaining Time" to the completion of the infusion toggled with the
remaining amount to be infused.
5. In addition to the display screen giving information regarding the status of the infusion, the
green LED light blinks whenever the pump is infusing.
e information on the run screen will alternate between a four-line display and a large-font display
of each line of information on the screen.
C o n t i n u o u s
Note: e top line of these running screens will display the name of the running protocol when
programmed in the Library mode, or it will display "Unidenti ed" when programmed outside of
the library.
e infusion can be paused at any time by pressing the PAUSE key.
blinks, and the Resume/Repeat Rx/New Program Menu screen is displayed.
e screen o ers you three options:
I n f o r m a t i o n
I nt e rrupt ing a n I nfusion
6 9
S c r e e n s
e yellow standby LED light
is
