Disposa ble Adm inist rat ion Se t I llust rat ions a nd Fe at ure s
Note: An important feature of the Curlin Medical administration set is the unique design of the
set-based Integral Flow-Stop. When the set is new, the Integral Flow-Stop has a breakaway tab
that keeps the Integral Flow-Stop open and allows the tubing to be gravity primed. When you are
ready to load the administration set into the pump, remove this tab, and the Integral Flow-Stop will
automatically clamp the tubing. The Curlin Medical Integral Flow-Stop prevents inadvertent flow
of medication to the patient whenever the door of the pump is opened because the Integral Flow-
Stop automatically reacts to clamp the tubing. The Integral Flow-Stop can, however, be opened after
the tab is broken away by intentionally squeezing down on the movable spring action section of
the Integral Flow-Stop. See Figure 1.6 for an illustration of how to intentionally open the Integral
Flow-Stop. For a complete listing of all available administration sets, see the Curlin Medical Product
Catalog.
Note: Administration sets with anti-siphon valve (ASV) protection can also be used for
.
additional free-flow protection
CAUTION: USE ONLY MOOG CURLIN INFUSION ADMINISTRATION
SETS WITH THIS PUMP
Figure 1 .3 Sa m ple s of M oog Curlin I nfusion Adm inist rat ion Se t s
