Moog Infinity INF0500-E Quick Start Manual

500ml Enteral Pump Delivery Set with ENFit
INSTRUCTIONS FOR USE: To ensure proper operation of the delivery set, please follow all instructions and illustrations below.
1. Fill feeding bag to desired level
and close cap securely.
2. Unscrew the protective cover counterclockwise
from the ENFit connector (image A).
Note: If set is to be used with a carry
pack, all air must be removed from the
bag and tubing. Continue to step #3 for
instructions on removing the air. If set is
to be hung above pump, i.e. on an IV pole,
air may remain in bag. Skip to step #4.
3. Turn bag upside down and gently squeeze. Tilt
bag to keep air at the tubing port (image B). At
the same time, follow the instructions in step #4.
4. Gently pinch the teal colored tubing below the
" " symbol (image C). Hold this position until
air is expelled from tubing. Gently squeeze
bag at the same time to assist fluid flow. If
fluid does not flow, pinch may be too tight.
WARNINGS AND PRECAUTIONS
• It is important to keep the air sensor free of debris including spilled fluids
or food that may adhere to the sensor and prevent detection of air in the
tubing. Use a cotton swab to clean the pathways of the cassette receptacle.
(Refer to the pump Operator's Manual for further cleaning instructions).
• When using a programmed dose, infinite dose or interval feeding setting, the
volume of food in the bag/bottle should be monitored throughout the feeding
cycle to ensure the appropriate dose has been received by the patient.
• Follow manufacturer guidelines related to maximum nutrition hang time.
• Device contains small parts. Dispose of or store connector cap when
not in use to avoid choking hazard for children under 3 years.
© 2022 Zevex, Inc. ENFit
Inc. For patent information, visit www.moogmedical.com/patents. Assembled in Costa Rica. Manufactured by Zevex, Inc. LS-80926 Rev. E
5. To expel air from tube using
pump prime feature, refer
to pump and Operator's
Manual for instructions.
Note: Priming with the pump
is recommended when using
thick formulas because it is
faster than priming by gravity.
6. Position silicone tubing
around pump wheel stretching
lightly. Seat cassette into
the pump (image D).
Close pump door.
7. Screw the ENFit connector
clockwise into feeding tube
firmly by hand (image E). Be
careful not to overtighten.
is a registered trademark of GEDSA. Infinity
®
Connector
®
• Avoid leaving tubing and cords where infants, children, or those
deemed at high risk for medical line entanglement, can become
entangled. Be aware that if these items become wrapped around a
patient's neck, there is an increased risk of strangulation or death.
Caregivers of patients who are at risk for entanglement should discuss
with their health care provider how to properly manage their lines
and properly monitor patients based on their needs while in use.
WARNING: This product can expose you to chemicals including
vinyl chloride, which is known to the State of California to cause
cancer. For more information go to www.P65Warnings.ca.gov.
THE INFINITY DELIVERY
SET IS INTENDED TO
CONNECT TO ENTERAL
FEEDING TUBES
is a registered trademark of Zevex, Inc. Moog
®
INF0500-E
A B
C D
E
DELIVERY SETS ARE
NOT
MADE WITH MATERIALS
MANUFACTURED
THAT DO NOT CONTAIN
WITH NATURAL
BISPHENOL A (BPA)
RUBBER LATEX
IN THE FLUID PATH.
