Note that the screen identi er gives the abbreviation "TPN" for Total Parenteral Nutrition and
has a down arrow con guration, which indicates that there are more than four elds of text or
information to be considered.
1. BAG Vol (IV Bag Volume): Use the numeric keys to enter the amount of uid in the IV Bag
or Medication Reservoir (include the over ll volume).
Note: e volume used for priming via the pump or for KVO is deducted from the Bag Volume.
erefore, Bag Volume should be equal to or greater than the Amount To Be Infused to start
the infusion.
When the correct amount has been entered, press the YES/ENTER key to accept this eld and
move on to the next.
2. VOL TBI (Volume To Be Infused): Use the numeric keys to enter the actual volume of
infusion to be delivered, excluding any KVO amounts. When the amount is correctly entered,
use the YES/ENTER key to accept this eld and to move to the next. (If VOL TBI entered is
greater than Bag Volume, the pump will beep once. An alert message of "AMT TBI GREATER
THAN BAG VOL" will appear to remind you to recheck and change the number before the
YES/ENTER key will accept the value and move to the next eld.)
to 9999.
3. Inf RATE (Infusion Rate or rate of the level infusion):
deliver from 0.1 mL to 400 mL per hour. Use the numeric keys to enter the prescribed rate.
When this eld is correct, use the YES/ENTER key to accept the rate and move to the next eld.
You may choose to let the pump calculate the rate by skipping this eld and entering the up
ramp time, down ramp, and total time.
4. UP Ramp: is optional feature allows the beginning of the infusion to be gradually tapered
up to the level infusion rate over a speci ed period of time. Enter the up ramp time period using
the numeric keys, and when correct, press the YES/ENTER key to accept this eld and move to
the next. Since this eld is optional, "0" may be entered and accepted.
0:00 to 9:00 HH:MM.
5. DN Ramp (Down Ramp):
down over a speci ed period of time at the end of the level infusion. Enter the down ramp time
period using the numeric keys, and when correct, press the YES/ENTER key to
T P N P r e s c r i p t i o n
e range for this eld is 1 to 9999.
is optional feature allows the infusion to be gradually tapered
9 3
S c r e e n
e range for this eld is 1
e Moog Curlin Infusion pump can
e range for this eld is
