accept and move the cursor to the next eld. Since this eld is optional, "0" may be entered and
accepted. e range for this eld is 0:00 to 9:00 HH:MM.
6. TotTime (Total Time):
be delivered, including up and down ramp times. When the pump is given the Volume To Be
Infused, the RATE at which to infuse, and the up and down ramp times, it will automatically
calculate the Total Time and display it here. Or you may choose to program the Total Volume
To Be Infused, Total Time and ramp times and let the pump calculate the level rate of infusion.
If so, the cursor will go back to the "Inf RATE" eld, display the rate, and require the operator
to accept it by pressing the YES/ENTER key. If the time is not acceptable, enter the new TIME
with the numeric keys. When the TIME eld is satisfactory, press the YES/ENTER key and
move to the nal eld.
Note: e time calculated by the pump may be less than a minute; however, one minute is the
minimum entry and display value.
7. KVO Rate (Keep Vein Open Rate):
the rate at which uid will be delivered in a "Keep Open" state.
0.1 mL/hour can be set from 0 to 10 mL/hour, but cannot be set at a rate to exceed the therapy
operating rate. When the desired KVO rate has been entered, press the YES/ENTER key to
accept and move the cursor to the next eld.
8. DONE?: If there are any changes to be made, use the up or down arrow keys to locate the
eld to be changed, enter the corrected information, and press YES/ENTER to accept the new
data. If all the elds are acceptable, at the "DONE?" prompt, press YES/ENTER to move to
the next screen.
I M PORTAN T
I N FORM AT I ON
e next screen that appears when the programming is complete o ers four choices:
Note that you do not need to answer yes or no questions or enter data with the numeric keys as
previously requested.
the requested function.
e IV bag and administration set should be inspected and be free of all air and air bubbles before
they are connected to the access site. Priming may have been done by gravity when the
is eld displays the entire time period over which the infusion will
e range for this eld is 0:01 to 288:00 HH:MM.
is eld requires data entry using the numeric keys to set
Before the infusion is started, it is important to consider a few
remaining issues, such as checking the administration set to be sure it
was primed or purged of all air, or perhaps the pump may need to be
put into a security lock setting for additional safety.
R u n O p t i o n s
is screen requires you to press the corresponding key on the keypad to begin
e following section explains each selection beginning with Prime:
Prim e
S c r e e n
9 4
e pump defaults to a rate of
