4. DN Occlu (Down Occlusion):
the line between the pump and the access site— e.g., a kink in the tubing between the pump
and the patient, a blockage in the access site, a clamp left on the distal tubing.
options for this eld: the "Low" setting (default setting) triggers the alarm when it detects in-
line pressures at 400 mmHg ±150 (8 ±3 psi "pounds per square inch"), or the "High" setting
alarms when it detects in-line pressures at 900 mmHg ±150 (18 ±3 psi). Press NO/CHANGE
to change the selection. When the correct pressure setting appears, press the "YES/ENTER"
key to accept it and move the cursor to the next eld.
5. AIR SENS (Air In Line Sensor):
will detect in the administration set tubing before it goes into an alarm state.
"0.1 mL," "0.5 mL" (the default setting), and "OFF." Press the NO/CHANGE key to change
the options until the desired setting appears on the display, and then press YES/ENTER to
select and move the cursor to the next line.
Whenever the Air-In-Line Sensor is set to OFF, Moog recommends
I M PORTAN T
the use of an air-eliminating lter.
I N FORM AT I ON
When the Air-In-Line Sensor is set to "OFF" and the RUN key is pressed at the Run Options
Screen, the alert message below will appear on the screen. It will also appear if the Air-In-Line
is changed from the Options Menu when an infusion is in progress and the AIR SENS eld is
accepted.
A i r - I n - L i n e
is message alerts you to the Air-In-Line Sensor being set to "OFF."
answering "yes" or "no" to whether the administration set being used has an air-eliminating
lter. If you press the YES key to indicate that there is an air-eliminating lter in use, the Air-
In-Line Sensor will be completely disabled and the pump will start the infusion.
If you press the NO key to indicate a lter is not in use, the Air-In-Line Sensor will be set to
detect the presence of any contiguous 2-milliliter air in the line.
then brie y appear on the screen. If the alert occurred at the Run Options Screen, the pump
will start the infusion.
A i r - I n - L i n e
is feature allows the pump to sense an occlusion pressure in
is feature allows you to select the amount of air the pump
S e n s o r O f f M e s s a g e
S e n s o r S e t a t 2 m L
1 2 7
ere are two
e choices are
S c r e e n
e message will require
e alert message below will
A l e r t S c r e e n
