If a pump goes into an error code, a numeric code will appear on the display screen. If this has
occurred, turn the pump o and back on. If the error code message does not reappear, continue
using the pump.
If the pump passes its start-up diagnostic tests, resume the therapy. If an error code recurs, turn
the pump o , replace it, and report the error code to the healthcare provider.
Error LCD Displayed
Code Message
11 Turn pump OFF/ON
Air Sensor
12
Turn pump OFF/ON or Call provider
Pressure Sens DN
13
Check Admin Set Turn Pump OFF/ON
Pressure Sens UP Check Admin Set
14
Turn Pump OFF/ON
Turn Pump OFF/ON or Call Provider
15
16
Turn Pump OFF/ON or Call Provider
17 Turn Pump OFF Call Provider
Call Provider
18
Turn Pump OFF Call Provider
19
Empty Lithium Battery Call Provider
20
Turn Pump OFF Call Provider
21
22
Turn Pump OFF Call Provider
23
Turn Pump OFF Call Provider
Turn Pump OFF Call Provider
24
25 Stalled Pump Turn Pump OFF/ON
Call Provider
26
Turn Pump OFF Call Provider
27
Turn Pump OFF Call Provider
Low Alarm Batt Connect AC Adapt
29
Turn pump OFF/ON
30 Turn Pump OFF
Call Provider
Turn Pump OFF
31
Call Provider
32
Turn Pump OFF
Call Provider
33
Low Alarm Audio
Connect AC Adapt
Turn Pump OFF/ON
34 Turn Pump OFF Call Provider
35 History File
Turn Pump OFF/ON
ERROR CODES
Probable Cause
Keyboard Buffer Full
Air-In-Line Test Circuit Failure
Bad Down Strain Beam
Bad Up Strain Beam
Bad Encoder
Bad Analog to Digital Conversion
Bad Clock
Bad Air In Line Comparator
Register Reading From Fpga.
Bad Door Sensor
Empty Lithium Battery
Bad Tristate Pin
Bad Test Pin
Bad Reverence Voltage
Bad Motor Supply
Broken Motor Shaft
Bad Motor Inhibit
Bad Motor Supply Enable
Low Auxiliary Battery
Bad Auxiliary Battery
Audio Main Speaker Low
Audio Main Speaker High
Audio Auxiliary Speaker Low
Audio Auxiliary Speaker High
History Log Erased
1 4 9
Corrective Action
Report Error Code To Factory
Report Error Code To Factor
Replace Set And Resume
Replace Set And Resume
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Report Error Code To Factory
Turn Power Off/On And Resume
Report Error Code To Factory
Report Error Code To Factory
Connect Pump To Ac Battery
Eliminator And Turn Power
Off/On To Pump. May Require
Turning Pump OFF/ON A Few
Times
Report Error Code To Factory
Report Error Code To Factory
Check/Replace D31. Replace
PCB
Connect Pump to AC Battery
Eliminator and Turn Power OFF/
ON to Pump. May Require
Turning Pump OFF/ON a Few
Times
Report Error Code To Factory
Report Error Code To Factory
