Moog Curlin 6000 CMS IOD User Manual page 108

Note: Whatever Down Ramp time was accepted in the prescription menu will appear as the
" DN Ramp" time on this screen.
accepted as already displayed. When correct, press the YES/ENTER key. When the new
time is accepted, the screen returns to the Options Menu.
begins when the Options Menu is exited and the pump is running.
5. DN Occlu (Down Occlusion):
the line between the pump and the access site— e.g., a kink in the tubing between the pump
and the patient, a blockage in the access site, or a clamp left on the distal tubing.
options for this eld: the "Low" setting (default setting) triggers the alarm when it detects in-
line pressures at 400 mmHg ±150 (8 ±3 psi "pounds per square inch"), or the "High" setting
alarms when it detects in-line pressures at 900 mmHg ±150 (18 ±3 psi). Press NO/CHANGE
to change the selection. When the correct pressure setting appears, press the YES/ENTER key
to accept it and move the cursor to the next eld.
6. AIR SENS (Air In Line Sensor):
will detect in the administration set tubing before it goes into an alarm state.
"0.1 mL," "0.5 mL" (the default setting), "2 mL," and "OFF." Press the NO/CHANGE key to
change the options until the desired setting appears on the display, and then press YES/ENTER
to select and move the cursor to the next line.
I M PORTAN T
I N FORM AT I ON
When the Air-In-Line Sensor is set to "OFF" and the RUN key is pressed at the Run Option
Screen, the alert message below will appear on the screen. It will also appear if the Air-In-Line
is changed from the OPTIONS menu when an infusion is in progress and the AIR SENS eld
is accepted.
A i r - I n - L i n e
is message alerts you to the Air-In-Line Sensor being set to "OFF."
answering yes or no to whether the administration set being used has an air-eliminating lter.
If you press the YES key to indicate that there is an air-eliminating lter in use, the Air-In-Line
Sensor will be completely disabled and the pump will start the infusion.
If you press the NO key to indicate a lter is not in use, the Air-In-Line Sensor will be set to
detect the presence of any contiguous 2-milliliter air in the line.
brie y appear on the screen. If the alert occurred at the Run Options Screen, the pump will start
the infusion.
is time can be changed using the numeric keys or
is feature allows the pump to sense an occlusion pressure in
is feature allows you to select the amount of air the pump
Whenever the Air-In-Line Sensor is set to OFF, Moog recommends
the use of an air-eliminating lter.
S e n s o r
9 8
O f f M e s s a g e S c r e e n
e alert message below will then
e Early Down Ramp phase
ere are two
e choices are
e message will require
