is information toggles with the following:
is screen displays as long as the infusion is running. Notice the information on each eld:
1. e rst eld displays the "RATE" of the infusion in whichever units/hour has been selected.
is eld toggles to also display the current dose # of total doses programmed.
2. e second eld is a graphic bar representing the percentage completed of the current dose.
e graphic bar will toggle with Line Pressure ("L Press") which displays the current
patient side (downstream) pressure in the administration set in millimeter of mercury
(mmHg) units.
3. e third eld displays "Total Volume Infused" (for entire therapy) and toggles with the amount
infused of the dose in progress, and Total Infused if units are in mg or mcg.
4. e fourth eld displays the remaining time to the completion of the total infusion and toggles
with total remaining volume to be infused, and total remaining amounts if units are in mg or
mcg.
5. In addition to the display screen giving information regarding the status of the infusion, the
green LED light blinks whenever the pump is infusing.
e information on the run screen will alternate between a four-line display and a large-font display
of each individual line of information on the screen.
V a r i a b l e
Note: e top line of these running screens will display the name of the running protocol when
programmed in the Library mode, or it will display "Unidenti ed" when programmed outside of
the library.
