is accessory becomes the external power source when plugged directly into the Moog Curlin
Infusion pump (see Figure 1.2 for external power port location on the bottom of the pump).
AC adaptor can also be used to recharge the portable battery pack by plugging the connecting cable
into the recharging port on the battery pack (see Figure 1.13).
ere are two AC adaptors:
•
e US Domestic AC Adapters 47684 and 57797 have a three-prong plug to
be plugged into a standard three-prong, grounded wall receptacle and a six-foot
cable which plugs into the power outlet on the bottom of the pump.
connector plugs into the receptacle by aligning the red dots on each.
•
e International AC Adapters 47685 AND 58831 are available for international use.
e two-pin connector plugs into the receptacle by aligning the key on the connector.
Note: Pause the pump and then turn it o before connecting the AC adaptor.
Note: e connector is keyed with a "notch" at this red-dot location to guide alignment. To
remove, pull back on the locking sleeve to unlock and then pull gently to remove the
connector from the battery pack or pump's port.
Two-pin adaptor plugs into port on bottom of the pump for AC
power or can be used to recharge the battery pack by plugging into
the recharging port on the battery pack (see Figure 1.12). To remove,
pull back on the locking sleeve.
AC Ada pt or/Cha rge r
Figure 1 .1 2 U nive rsa l AC a da pt or
3 0
e
e two-pin
