ETC Obsession User Manual page 339

Appendix B DIP switch and jumper settings
Remote Video Interface (RVI)
Main DIP switch settings - RVI board
The RVI processor board is the lower circuit board in the Remote
Video Interface. This board contains one 8-switch DIP switch unit.
Normally these switches do not need to be changed.
To change switch settings, find the switches (see page 335) and
set them as shown below. The RVI checks switch settings when
it is turned on . You must restart the RVI for new settings to take
effect. Switches are either On (Closed) or Off (Open).
DIP Switch
1
On (Closed)
2 through 5
Off (Open)
6 and 7
On (Closed)
8
Off (Open)
Function
Factory Use Only
Normal operation
Factory Use Only
Unused
Factory Use Only
Normal operation
Factory Use Only
Unused
