ETC EUTRAC Planning And Installation Manual

Datatrack system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Table of Contents

Chapter 1
Chapter 2
Chapter 3
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 1
About DataTrack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Load Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . .2
General Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Help from ETC Technical Services . . . . . . . . . . . . . . . . .4
Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Planning the Track Layout . . . . . . . . . . . . . . . . . . . . . . .5
Planning the Installation . . . . . . . . . . . . . . . . . . . . . . . .5
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Ground Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Suspended Load Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
DMX Data Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installation . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cutting Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installation Methods . . . . . . . . . . . . . . . . . . . . . . . . . .12
Surface Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Suspension Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installing End Feeds . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Installing Mid Feeds . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Installing Current Limiters . . . . . . . . . . . . . . . . . . . . . .21
Flexible or Rigid Conduit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Wiring End Feeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Wiring In-line Feeds . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Powering On DataTrack . . . . . . . . . . . . . . . . . . . . . . . .24
Troubleshooting . . . . . . . . . . . . . . . . . . . . 25
Loss of Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Data Issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
i
