ETC Obsession User Manual page 205

Chapter 14 Profiles
Profile display
The profile display screen shows you the last selected profile and
allows you to edit that profile.
Profile 12— Master profile
% Complete 0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
Intensity
Intensity
Profile 12 •
S1
Clear
All
The profile's number and label
The percentage of fad completion, in five percent incre-
ments. The currentl selected fade point is highlighted.
The level assigned t each fade point. ** indicates that no lev-
el is assigned to hat point.
Graph showing the relationship between the fade points and
the ade level.
Ve tical bars showing the profile's curve. Every other bar cor-
responds to a fade point's level.
0 10 20 30 40 50 50 50 50 50 50 50 50 50 50 50 60 70 80 90 FL
FL
80
60
40
20
0
0 10 20 30 40 50
% Fade Completion
S2 S3 S4 S5
Clear To Fill
End Between
205
60 70 80 90 100
S6 S7 S8
opy To Reset Setup
Profile Profile Menu
