ETC Obsession User Manual page 317

Appendix A Installation
Installing a printer
Obsession supports parallel printers, including some laser
printers . Among the printers supported are the IBM Proprinter,
Epson FX80 and Canon Bubblejet.
1. Insert parallel printer cable into connector labeled Parallel
Printer on the console's back panel.
2. Insert opposite end of the printer cable into the printer.
3. Turn printer power switch on, and verify that printer is on line.
Console connector
DB25F
Pinout
1
2
3
4
5
6
7
8
9
10
11
12, 13
14 to 17
18 to 25
Printer connector
Centronics D36
Signal Pinout
STRB 1
D0 2
D1 3
D2 4
D3 5
D4 6
D5 7
D6 8
D7 9
ACK 0
Busy 11
Not u ed 12, 18
nc 13 to 15, 17, 19 to 36
Gr und 16
317
